Visual studio is one of the widely used IDE for software development. So, in Teamcenter ITK development also we use this IDE. Apart from visual studio dependency files (.h, .dll, and .lib, etc), Teamcenter dependency files are also required for ITK development. Once visual studio is installed, it should be configured for Teamcenter ITK development.

Before configuring, create a project as below

In Visual studio Editor: Click on File–>New–>Project

Select Win32 Console Application. Input the solution name and project name

DLL: Select DLL radio button and select “Empty project” in Additional options

EXE: Select “Console application” and select “Empty project” in Additional options.

Create a new .cpp file or add existing .cpp file under “Source File” folder in the project.

Set the below variables in the properties page (Right click–>Properties) of the project:

  1. Additional Library Directory–>lib directory path of the Teamcenter installation location
  2. Enable Incremental Linking–>No

3. Configuration Type–>DLL/EXE (as needed)


Teamcenter Unified Data Model Concept


4. Environment–>set TC_ROOT and TC_DATA path and call tc_profilevars.bat

5. Additional Include Directory–>$(TC_ROOT)\include and $(TC_ROOT)\include_cpp

6. Optimization=Disabled

7. Preprocessor Definitions–>IPLIB=none


Teamcenter Greenfield Implementation


8. Runtime Library–>Multi-threaded DLL

9. Additional Dependencies–> $(TC_ROOT)\lib\*.lib

10. Additional Library Directories–> $(TC_ROOT)\lib

11. Generate Debug Info–> Yes

12. SubSystem–> Console



Click OK.
