You can use the UserService mechanism to call your ITK functions from Java in the rich client.

First register your ITK functions in the user_server_exits.c file.

Compile this file and your source code and link them into the libserver_exits library to make the functions available to the rich client.

  1. In the TC_ROOT\bin directory, back up your old library file (dll in Windows; libserver_exits.so or libserver_exits.sl in UNIX or Linux).
  2. Copy the c and user_server_exits.h files from the TC_ROOT/sample/userservice directory to your working folder.
  3. Register your ITK functions in the c file.

    Example:-
    if you wanted to register an ITK function called PasteRevToNewstuff in the user_server_exits.c file,The File would look like figure 1-6.

#include <server_exits/user_server_exits.h>

#include <userservice.h>

extern DLLAPI int USERSERVICE_register_methods ()

{

int status = ITK_ok;

int iNumberOfArgs = 0;

int *piArgTypes = NULL;



/*

* This function registers the server side user defined functions for the

* CORBA server

*/



iNumberOfArgs = 2

piArgTypes = (int*) SM_alloc_persistent (iNumberOfArgs * sizeof (int));

piArgTypes[0] = USERARG_STRING_TYPE;

piArgTypes[1] = USERARG_STRING_TYPE;



USERSERVICE_register_method( “PasteRevToNewstuff”, PasteRevToNewstuff, iNumberOfArgs,piArgTypes,USERARG_TAG_TYPE);

return (status);

}


PLM: Introduction of Teamcenter Cloud


 user_server_exits.c file

Example:-

If you want to use an array, add the + USERARG_ARRAY_TYPE declaration to the argument declaration.

For Example:- To make  the piArgTypes[1] argument in figure 1-6 a string array instead of only a string, change the line to this:

piArgTypes[1] = USERARG_STRING_TYPE + USERARG_ARRAY_TYPE;

If you want to return the strings from the array, use the USERSERVICE_return_string_array function.

  1. If you are using Windows, compile your code and the c file using the compile.bat script in the TC_ROOT\sample directory with the following command:

%TC_ROOT%\sample\compile —DIPLIB=libserver_exits user_server_exits.c your-source-code.c




Introduction of Teamcenter Active Workspace Architecture


If you are using UNIX or Linux, see the Compiling section for the command.

  1. Link the server exits using the link_server_exits script in the TC_ROOT\sample directory with the following command:

     TC_ROOT\sample\link_server_exits

  1. Copy the new library file to the TC_ROOT\bin

You can then call your ITK functions from the rich client.

For example:-

if you wanted to call the PasteRevToNewstuff function from a JPanel component within an application,

import java.lang.Object;

import java.awt.*;

import javax.swing.*;

import java.awt.event.ActionEvent;

import java.awt.event.ActionListener;

import com.teamcenter.rac.aif.*;

import com.teamcenter.rac.aif.kernel.*;

import com.teamcenter.rac.kernel.*;

import com.teamcenter.rac.util.*;



public class NewAppApplicationPanel extends JPanel

{

JTextPane JTextPane1 = new JTextPane();

private AbstractAIFUIApplication application = null;

private TCSession  session = null;

private TCUserService  service = null;

private TCComponent  component = null;



public class NewAppApplicationPanel( AbstractAIFUIApplication app )

{

super (new BorderLayout());



application = app;

session = (TCSession)application.getSession();



try

{

service = (TCUserService)session.getUserService();

}

catch( TCException e )

{

}



JtextPane1.setCaretColor(Color.red);

JtextPane1.setText(“Welcome”);

JtextPane1.setForeground(Color.magenta);



this.add (JTextPane1, null);



add( “North”, app.getApplicationHeader());

Object objs[] = new Object[2];



String itemID = new String( “000001”);

String revID = new String( “A”);

objs[0] = itemID;

objs[1] = revID;

try

{

component = (TCComponent) service.call( “ACME_PasteRevToNewstuff”, objs);

}



catch( TCException e )

{

MessageBox msgBox = new MessageBox( e );

msgBox.setModal( true );

msgBox.setVisible( true );

}

}

public NewAppApplicationPanel()

{

try

{

jbInit();

}  catch( Exception e )

{

e.printStackTrace();

}

}

private void jbInit() throws Exception

{

}

}
